Pitch 3.81mm / 0.15" screw terminal block.
Simple DIN Adapters (Feet): for width 35 / 32 / 15mm DIN rails.
Solder connection holes, three (3) per line, supports addition of 0.1" pin headers.
FR-4 fiber glass PCB, dual copper layers.
External dimensions: 89 x 49.5 x 38mm (W x L x H).
Rated voltage: 100V.
Rated current: 0.5A / per pin.
Operating Temperature: -20ºC to 50ºC
Terminal block specifications:
Wire range: 26 ~ 16AWG.
