Copper Wire Crimp Connector Cable Non-insulated Spade Terminals Kit

Specifications:

Rohs: All kinds of our products are ROHS compliant.

1 Product Name :ASsorted Non-Insulated
Terminals(Ring Fork U-Type Spade Non-insulated terminal)
2.Material of Body : Brass
3 Surface : Tin-Plated
4 Material of Insulation : PVC Tube
Specifications:
1) 20PCS Ring Spade Non- Insulated Terminal 22-16AWG #4 19AMP (RNB 1.25-3)
2) 20PCS Ring Spade Non- Insulated Terminal 16~14AWG #4 27AMP (RNB 2-3)
3)15PCS Ring Spade Non- Insulated Terminal 12~10AWG #8 48AMP (RNB5.5-4)
4) 20PCS Fork Spade Non- Insulated Terminal 22-16AWG #4 19AMP (SNB 1.25-3)
5)20PCS Fork Spade Non- Insulated Terminal 16~14AWG #4 27AMP (SNB 2-3)
6)15PCS Fork Spade Non- Insulated Terminal 12~10AWG #8 48AMP (SNB5.5-4)
7) 20PCS Ring Spade Non- Insulated Terminal 22-16AWG #8 19AMP (RNB 1.25-4)
8) 20PCS Ring Spade Non- Insulated Terminal 16~14 AWG #8 27AMP (RNB 2-4)
9)15PCS Ring Spade Non- Insulated Terminal 12~10AWG #10 48AMP (RNB5.5-5)
10) 20PCS Fork Spade Non- Insulated Terminal 22-16AWG #8 19AMP SNB (1.25-4)
11) 20PCS Fork Spade Non- Insulated Terminal 16~14AWG #8 27AMP (SNB 2-4)
12) 15PCS Fork Spade Non- Insulated Terminal 12~10AWG #8 48AMP (SNB5.5-4L)
13) 20PCS Ring Spade Non- Insulated Terminal 22-16AWG #10 19AMP (RNB 1.25-5)
14) 20PCS Ring Spade Non- Insulated Terminal 16~14 AWG #10 27AMP (RNB 2-5)
15)15PCS Ring Spade Non- Insulated Terminal 12~10AWG 1/4 48AMP (RNB5.5-6)
16) 20PCS Fork Spade Non- Insulated Terminal 22-16AWG #10 19AMP (SNB 1.25-5)
17) 20PCS Fork Spade Non- Insulated Terminal 16~14AWG #10 27AMP (SNB 2-5)
18) 15PCS Fork Spade Non- Insulated Terminal 12~10AWG #10 48AMP (SNB5.5-5)
Totally 330pcs/kit

QC: Passed TS 16949 Quality control system.All the products are 100% test before delivery.

EmergencyGoods: Great freight discount to ship emergency goods by UPS, FedEx, DHL,TNT or air cargo.

Terminals Kit: 18 values, 330 pcs in a plastic case

Whosale: 1000pcs a pack / per line item
